Product Description

1. The performance of our compact transformer substation conform to the standard of GB 1094-1996 “Power Transformer “ and GB/T6451-2008 “Technical Parameter and requirements of Three-phase Oil-immersed Power Transformer”.
2 The iron core is made of quality cold –rolled silicon steel sheet , and the coil is made of quality oxygen-free copper, featuring good outlook and safe running.
3 The products are widely used in power transmission and distribution of industrial and agricultural power networks.
4 Iron core is made of cold-rolled silicon-steel sheet with high conduction of magnetism and adopts pulling-plank structure, so that its magnetic route is short, losses and noise level is low;
5 Compress wire is adopted for winding so losses are low and have good ability withstand short-circuit;
6 Its active part adopts special pressing method which could ensure reliable axial pressure;
7 The oil tank is bell type with the structure of full folding plate type, having an excellent exterior and easy for maintenance;
8 Reliability: All in-service product have no damages or oil leakage occurred;
9 Oil tank with various kinds of structure and good appearance.

Specification

Company Profile

1.Chongqing Bosun Electrical Co., Ltd. was established in 1996, located in Banan District Chongqing China, with convenient transportation, covers an area of 8,000 square meters.

2.Devoted in the research and development, manufacturing, installation, and sales of complete sets of high and low voltage switchgear and control equipment from 40.5kV to 0.22kV.

3.more than 20 CCC/CQC certificates, meet the requirements of the highest protection level of IP65 and altitude environment of 4500 meters, get the GB/T19001:2016 /ISO9001:2015 quality management system certification,

4.A complete product development department, design team.

5.Various kinds of product construction and manufacturing design by using specialized computer mechanical and electrical CAD design software systems.

6.Complete surveillance, measuring, and testing equipment to ensure the high products quality.

7.Complete production line including CNC processing equipment, welding equipment, and hoisting equipment required for cabinet production, busbar bending equipment, tinning equipment, electric tools, and other assembly production equipment required for complete assembly production.

8.More than 10 product invention patents and utility model patents.

9.Excellent service based on the motto "Quality First, Customer Foremost, Survival Through Quality, Development Through Service, Continuous Improvement."

Material

1.The cabinet door adopts a double beveled edge process, which increases the structural strength of the same material by 50%.

2.The installation holes are all made using a multi-layer stamping and stretching process, which reduces the sliding wire situation by more than 80%.

3.The inlet and outlet holes adopt a composite structure of knockdown holes and square holes, which can be flexibly selected during on-site installation.

4.The box adopts a double folding process, which increases the structural strength of the same material by 50%.

5.The control circuit adopts a composite design of debugging mode and fire protection mode, greatly reducing the burning of fan and water pump equipment designed for fire protection during debugging.
