Product Name: High Voltage Switchboard Rated Voltage: 12KV,40.5kV,36kV,0.4kV
Rated Current: 630A,1600A,2000A,2500A,4000A Material: Steel,galvanized Sheet Etc.,galvanized Steel Or Aluminum
Color: As Required Payment: T/T L/C
High Light:

Electrical Grid System high voltage switchboard

,

4 Phase high voltage switchboard

,

GIS GAS Insulated switchboard switchgear

4 Phase GIS GAS Insulated High Voltage Switchboard for Electrical Grid System​





Product Description



  • The KYN61-40.5 switchgear is a three-phase single switchgear designed for power generation plants, substations, industrial and mining enterprises, and high-rise building distribution systems.
  • The switchgear receives and distributes electrical energy while controlling, protecting, and monitoring electrical circuits. It meets the requirements of IEC60298, DL404, and other standards and has complete "five-proof" functions.
  • The switchgear can operate in ambient air temperatures between -10℃ to +40℃, at an altitude not exceeding 1000m, and with a seismic intensity not exceeding 8 degrees. The ambient air should not be subject to significant pollution such as corrosive, flammable gases, water vapor, etc.
  • The KYN61-40.5 switchgear features a compact cabinet structure due to the use of heat shrinkable insulation materials, epoxy-coated insulation technology, and optimized electrode shape. The switchgear cabinet body is made of high-quality cold-rolled steel.
  • The switchgear can use both domestic ZN85-40.5 vacuum circuit breakers and French SF1, SF2, and FP system sulfur hexafluoride circuit breakers. The main busbar scheme can reach more than 198 types, providing strong adaptability to different user needs.
  • Each functional compartment of the switchgear is sealed with a metal plate and has an independent pressure release channel. The mechanical interlocking device between the handcart, circuit breaker, grounding switch, and rear cabinet door prevents misoperation, and the "five-proof" functions ensure complete safety and reliability.



Main Technical Parameters



Main Technical Parameters Specifications
Rated voltage 40.5KV
Rated frequency 50Hz
Rated current of the main busbar 1250A, 1600A, 2000A
Rated insulation level 1min power frequency withstand voltage 95KV between phases and relative, 115KV for the first isolating joint
Lightning impulse withstand voltage 185KV between phases and relative, 215KV for the first isolating joint
1min power frequency withstand voltage of the auxiliary control circuit 2KV
Dimensions (widthdepthheight) 1400*2800(3000)*2800
Rated current of branch busbar 630A, 1250A, 1600A
